目录说明

Key Features

• aMLC (advancedMLC technology
/1-bit per Cell) NAND Flash
• Advanced Wear Leveling algorithm
• Bad Block Management
• Read Disturb Protector - AutoRefresh
to ensure data integrity during read
operation
• Enhanced F/W algorithm to minimize
the risk of a sudden power-off
• Water proof, Dust proof and ESD resistant
• Highly reliable and pass environmental
test (Bend/Torque/Salt Spray/Solar
radiation)
• Life Monitor (Note : The compatibility
and support of Life Monitor may vary
on different platform/operation
system)



Applications

• Industrial PCs
• Medical devices
• Automotive IVI systems
• Drive recorders
• Surveillance systems
• Navigations
• Test and Measurement
• Mobile/Handheld computers
• Automation


详细介绍




ATP aMLC (advancedMLC),SDHC/microSDHCTargeted Product Portfolio, Engineered Specifically for Your Mission Critical
Applications,ATP aMLC SDHC/microSDHC cards are designed for most up-to-date,industrial applications, such as surveillance, medical imaging,transportation, drive recorder and automation where customers require higher reliability, endurance and performance but also seek,for cost-effective solution to meet their budget. ATP aMLC SD/microSD cards are considered as escalation of MLC memory cards. With advanced firmware algorithm, ATP aMLC technology manipulates MLC flash 2 bits each cell into 1 bit to improve aMLC product spec in all respects. ATP aMLC memory cards with overall upgrades, 13X endurance, 1.5X write performance, 5X data retention improvement compared with traditional MLC cards. aMLC is suitable for intensive write applications due to increasing endurance (40K P/E cycles) and enhanced write speed. Nonetheless, it's also a reliable solution for read applications owing to the faster read performance and Read Disturb Protector – AutoRefresh technology to assure the data integrity at the same time. Moreover, with SIP (System-In-Package) manufacturing process, the operating/storage temperature of

ATP aMLC SD/microSD cards is -25 to 85 degrees Celsius. ATP aMLC memory cards passed a series of power cycling test and thorough evaluation process. Each aMLC card,will conduct 100% production level burn-in test before delivering to customers.

Key Features

• aMLC (advancedMLC technology /1-bit per Cell) NAND Flash
• Advanced Wear Leveling algorithm
• Bad Block Management
• Read Disturb Protector - AutoRefresh to ensure data integrity during read operation
• Enhanced F/W algorithm to minimize the risk of a sudden power-off
• Water proof, Dust proof and ESD resistant
• Highly reliable and pass environmental test (Bend/Torque/Salt Spray/Solar radiation)
• Life Monitor (Note : The compatibility and support of Life Monitor may vary on different platform/operation system)

Applications

• Industrial PCs
• Medical devices
• Automotive IVI systems
• Drive recorders
• Surveillance systems
• Navigations
• Test and Measurement
• Mobile/Handheld computers
• Automation



新闻部分:
1:ATP Industrial Grade CompactFlash Card 512MB TO 32GB
2:ATP aMLC (advancedMLC),SDHC/microSDHCT
3:ATP Industrial Grade CompactFlash Card 8GB TO 32GB
4:ATP Industrial Grade SD/SDHC/SDXC
5:ATP SD/SDHC/SDXC Card Industrial Grade

型号如下:
SD / SDHC (SLC) SDHC / SDXC (MLC) microSD / microSDHC (SLC) microSDHC (MLC)
AF512SDI-OEM AF8GSD3-OEM AF512UDI-OEM AF8GUD3-OEM
AF1GSDI-OEM AF16GSD3-OEM AF1GUDI-OEM AF16GUD3-OEM
AF2GSDI-OEM AF16GSD3-OEM* AF2GUDI-OEM AF32GUD3-OEM
AF4GSDI-OEM AF32GSD3-OEM AF4GUDI-OEM
AF8GSDI-OEM AF64GSD3-OEM* AF8GUDI-OEM
AF16GSDI-OEM AF128GSD3-OEM*
AF32GSDI-OEM
